Starters for Forklift - Today's starter motor is usually a permanent-magnet composition or a series-parallel wound direct current electrical motor together with a starter solenoid mounted on it. As soon as current from the starting battery is applied to the solenoid, basically via a key-operated switch, the solenoid engages a lever that pushes out the drive pinion that is located on the driveshaft and meshes the pinion with the starter ring gear that is seen on the flywheel of the engine.
As soon as the starter motor starts to turn, the solenoid closes the high-current contacts. When the engine has started, the solenoid has a key operated switch which opens the spring assembly to pull the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This permits the pinion to transmit drive in just one direction. Drive is transmitted in this way via the pinion to the flywheel ring gear. The pinion continuous to be engaged, for example for the reason that the operator did not release the key when the engine starts or if there is a short and the solenoid remains engaged. This causes the pinion to spin separately of its driveshaft.
The actions mentioned above will stop the engine from driving the starter. This important step prevents the starter from spinning so fast that it could fly apart. Unless modifications were made, the sprag clutch arrangement would prevent using the starter as a generator if it was utilized in the hybrid scheme mentioned prior. Usually a regular starter motor is designed for intermittent utilization which would stop it being utilized as a generator.
The electrical parts are made so as to work for roughly thirty seconds to be able to avoid overheating. Overheating is caused by a slow dissipation of heat is due to ohmic losses. The electrical parts are meant to save cost and weight. This is really the reason the majority of owner's manuals for automobiles suggest the driver to stop for a minimum of 10 seconds after each ten or fifteen seconds of cranking the engine, when trying to start an engine that does not turn over immediately.
The overrunning-clutch pinion was launched onto the marked during the early 1960's. Before the 1960's, a Bendix drive was utilized. This drive system operates on a helically cut driveshaft that consists of a starter drive pinion placed on it. Once the starter motor begins turning, the inertia of the drive pinion assembly enables it to ride forward on the helix, hence engaging with the ring gear. Once the engine starts, the backdrive caused from the ring gear allows the pinion to go beyond the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.
In the 1930s, an intermediate development between the Bendix drive was made. The overrunning-clutch design that was made and launched in the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive has a latching mechanism along with a set of flyweights inside the body of the drive unit. This was an improvement in view of the fact that the average Bendix drive used so as to disengage from the ring once the engine fired, even though it did not stay running.
When the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is attained by the starter motor itself, like for example it is backdriven by the running engine, and afterward the flyweights pull outward in a radial manner. This releases the latch and enables the overdriven drive unit to become spun out of engagement, thus unwanted starter disengagement could be avoided prior to a successful engine start.
