Throttle Body for Forklift - The throttle body is a component of the intake control system in fuel injected engines to be able to regulate the amount of air flow to the engine. This particular mechanism operates by placing pressure on the operator accelerator pedal input. Usually, the throttle body is positioned between the intake manifold and the air filter box. It is often connected to or located close to the mass airflow sensor. The largest piece within the throttle body is a butterfly valve called the throttle plate. The throttle plate's main task is so as to control air flow.
On the majority of automobiles, the accelerator pedal motion is transferred via the throttle cable, therefore activating the throttle linkages works in order to move the throttle plate. In cars with electronic throttle control, also called "drive-by-wire" an electric motor regulates the throttle linkages. The accelerator pedal is attached to a sensor and not to the throttle body. This sensor sends the pedal position to the ECU or Engine Control Unit. The ECU is responsible for determining the throttle opening based upon accelerator pedal position together with inputs from other engine sensors. The throttle body has a throttle position sensor. The throttle cable is attached to the black portion on the left hand side that is curved in design. The copper coil located close to this is what returns the throttle body to its idle position once the pedal is released.
Throttle plates revolve inside the throttle body each time pressure is placed on the accelerator. The throttle passage is then opened to be able to enable more air to flow into the intake manifold. Typically, an airflow sensor measures this adjustment and communicates with the ECU. In response, the Engine Control Unit then increases the amount of fluid being sent to the fuel injectors in order to produce the desired air-fuel ratio. Often a throttle position sensor or TPS is fixed to the shaft of the throttle plate to be able to provide the ECU with information on whether the throttle is in the wide-open throttle or otherwise called "WOT" position, the idle position or somewhere in between these two extremes.
Several throttle bodies may include valves and adjustments so as to control the minimum airflow during the idle period. Even in units that are not "drive-by-wire" there would normally be a small electric motor driven valve, the Idle Air Control Valve or IACV which the ECU uses so as to regulate the amount of air that can bypass the main throttle opening.
In various automobiles it is normal for them to contain a single throttle body. In order to improve throttle response, more than one could be utilized and attached together by linkages. High performance automobiles like for instance the BMW M1, along with high performance motorcycles like for instance the Suzuki Hayabusa have a separate throttle body for each and every cylinder. These models are referred to as ITBs or likewise known as "individual throttle bodies."
A throttle body is similar to the carburetor in a non-injected engine. Carburetors combine the functionality of the throttle body and the fuel injectors into one. They operate by blending the fuel and air together and by modulating the amount of air flow. Automobiles which include throttle body injection, that is known as CFI by Ford and TBI by GM, situate the fuel injectors in the throttle body. This allows an old engine the opportunity to be transformed from carburetor to fuel injection without really altering the engine design.
